6
OTHER FUNCTIONS
6-10
Using the Simple MIC function
The Simple MIC function enables controlling the
transceiver through your control unit attached to the
[SP] jack�
NOTE: BE SURE to turn OFF the transceiver when
plugging or unplugging the headset into or from the
[SP] jack�
+
‒
2.7kΩ 6.8kΩ 15kΩ 33kΩ
S1 S2 S3 S4
Remote control unit
To the ［SP］ jack
GND
SP
REMOTE
Rated input ： 700 mW （8Ω） or more
External speaker
3.5（d）mm
• SImPLE
S1 Selects a Call channel�
S2 Turns the Monitor function ON or OFF�
S3 Selects memory channel 0�
S4 Selects memory channel 1�
• nORm-1
S1 Toggles between the VFO mode and
Memory mode�
S2 Selects a Call channel�
S3 Frequency or memory channel “UP�”
S4 Frequency or memory channel “DOWN�”
• nORm-2
S1 Toggles between the VFO mode and
Memory mode�
S2 Turns the Monitor function ON or OFF�
S3 Frequency or memory channel “UP�”
S4 Frequency or memory channel “DOWN�”
• Common (SImPLE, nORm-1, nORm-2)
S2 Transmits t-CALL (1750 Hz tone) while
holding down [PTT]�
S3 Enters the Squelch adjustment mode while
using the Monitor function�
S4 Enters the Squelch adjustment mode while
using the Monitor function�
