8-18
BASIC MANUAL
SET MODE
8
8
Display
MENU
»
SET > Display
LCD Backlight (Default: 50%)
Sets the LCD backlight brightness.
LED Bright (Default: 80%)
Sets the LED brightness.
Display Font (Default: Round)
Selects the font for the frequency readout.
Meter Response (Standard, Edgewise)
(Default: Mid)
Sets the meter needle response speed to Slow, Mid,
or Fast.
Meter Type (Normal Screen) (Default: Standard)
Meter Type (Expand Screen) (Default: Bar)
Sets the S/RF meter type for each display to
Standard, Edgewise, or Bar.
Meter Peak Hold (Bar) (Default: ON)
Turns the Meter Peak Hold function ON or OFF.
Memory Name (Default: ON)
Turns the Memory name display in the Memory mode
ON or OFF.
MENU
»
SET > Display > Filter Eect Screen
Waveform Type (Default: Fill)
Selects the outline waveform display for the FFT
scope.
• Fill: Displays only the waveform, in color.
• Fill+Line: Displays both the waveform and the
outline, in color.
Waveform Color (Default: (R) 51 (G) 153 (B) 255)
Sets the waveform color for the FFT scope.
L Touch and select the R (Red), G (Green), or B (Blue)
scale, and then rotate
MULTI
to adjust the level from 0
to 255.
L The color is displayed in the box above the RGB scale.
MENU
»
SET > Display
Screen Saver (Default: 60min)
Sets the Screen Saver function.
This function activates and automatically turns OFF
the screen when no operation is performed for the
preset period of time.
L While this function is activating, the indicator on
NR
blinks white.
External Display (Default: OFF)
Select “ON” when using an external display.
External Display Resolution (Default: 800x480)
Select the screen resolution of the external display.
Opening Message (Default: ON)
Selects whether or not to display the opening
message at power ON.
My Call
Sets a text displayed as the opening message, up to
10 characters. (Example: your call sign)
Display Language (Default: English)
Sets the screen display language to English or
Japanese.
