3-7
BASIC MANUAL
3
BASIC OPERATION
Entering the Split Frequency Oset on the Main
screen
1. Touch the MHz digits. (Example: 14)
• Opens the BAND STACKING REGISTER screen.
2. Touch [F-INP].
• Opens the F-INP screen.
3. Enter the Split Frequency Offset.
L Information
• If you want the minus shift direction, touch [•(−)].
• Enter the oset between −9.999 MHz and +9.999 MHz
(1 kHz steps).
• To clear the entry, touch [CE].
• To clear the entry and return to the previous screen,
touch
.
4. To save the entry, touch [SPLIT] or [−SPLIT].
• Closes the F-INP screen.
• The Split function is automatically turned ON.
[SPLIT] or [-SPLIT]
is displayed.
Displayed
Shifted by the oset amount.
D Directly entering a frequency
Setting the frequency
Entering the Split Frequency Oset on the Sub
screen
1. Push
SUB DISP
several times to display the
Keypad screen.
2. Touch [F-INP].
SUB DISP
Band keypad
• Opens the Tenkey pad.
3. Enter the Split Frequency Offset.
4. To save the entry, push
SPLIT
.
• Returns to the Band keypad.
• The Split function is automatically turned ON.
Main screen
Sub screen
Main screen
Displayed
Shifted by the oset amount.
NOTE: If the entered operating frequency is out of an amateur band’s frequency range, the transmit frequency is
automatically set to the band edge frequency.
Entry examples
• 5 kHz: [5], [SPLIT] • −10 kHz: [•(−)], [1], [0], [−SPLIT]
