3-5
BASIC MANUAL
3
BASIC OPERATION
D About the Auto Tuning Step function
The tuning step automatically changes, depending on
the rotation speed of
MAIN
DIAL
.
L You can change the Auto Tuning Step function settings in
the following setting. (p. 8-6)
MENU
»
SET > Function > MAIN DIAL Auto TS
D About the 1/4 Tuning function
SSB-D, CW, RTTY, and PSK modes
With the Tuning Function OFF, turn ON the 1/4 Tuning
function to reduce the tuning speed to 1/4 of the
normal speed, for ner tuning.
z Touch [1/4] to turn the 1/4 Tuning function ON or
OFF.
Setting the frequency
D Using the Main Dial
1. Select the desired operating band. (p. 3-3)
2. Rotate
MAIN
DIAL
.
• The frequency changes according to the selected
Tuning Step.
L
is displayed when you select an amateur radio
frequency, and
(with a dotted line) is displayed
when you select a frequency outside the Ham band,
or outside your set Band Edges.
D About the Tuning Step function
You can set the
MAIN
DIAL
’s tuning step for each
operating mode.
z Touch the kHz digits to turn the Tuning Step
function ON or OFF.
• The Tuning Step function’s icon “▼” is displayed above
the 1 kHz digit.
D About the 1 Hz step Fine Tuning
function
You can use the minimum tuning step of 1 Hz for ne
tuning.
z Touch the Hz digits for 1 second to turn the Fine
Tuning function ON or OFF.
L When using the [UP]/[DN] keys on the microphone, the
frequency changes in 50 Hz steps with the Fine Tuning
function ON or OFF.
D Changing the Tuning Step
When the Tuning Step function is ON, you can change
the tuning steps for each operating mode.
1. Select the desired operating mode. (p. 3-4)
(Example: USB)
2. Touch the kHz digit for 1 second.
• Opens the TS (SSB) screen.
3. Touch the desired tuning step. (Example: 0.1 k)
• The tuning step is set, and returns to the previous
screen.
The Tuning Step
function is ON.
The 1 Hz digit is
displayed.
1/4 Tuning
function is ON.
