XTK-A series
5
www.ibiza-light.com
REAR PANEL
XTK8A & XTK10A XTK12A & XTK15A
1 Mic volume control Mic volume control
2 Echo control Echo control
3 Treble control for high frequencies Treble control for high frequencies
4 Bass control for low frequencies Bass control for low frequencies
5 Line input level control Line input level control
6 Power LED indicator 6.35mm microphone 1 input
7 6.35mm microphone 1 input 6.35mm microphone 2 input
8 MIC/LINE switch MIC/LINE switch
9 XLR MIC/LINE input XLR MIC/LINE input
10 RCA phono (R+L) line input RCA phono (R+L) line input
11 RCA Line output RCA Line output
12 Speaker out (8 Ohm) Power LED indicator
13 Mains power switch 115/230V switch
14 Fused IEC mains input Speaker out (8 Ohm)
15 Mains power switch
16 Fused IEC mains input
CARE
The product should be cleaned only with a polishing cloth or a soft dry cloth. Never clean with furniture wax,
benzene, insecticides or other volatile liquids since they may corrode the cabinet.
SPECIFICATIONS
XTK8A XTK10A XTK12A XTK15A
System Active 2-way full range
Woofer 8” 10” 12” 15”
Tweeter 1” 1.34”
RMS power 100W 150W 250W 300W
Impedance 8 Ohm
Freq. Range 50Hz – 18kHz 45Hz – 18kHz 40Hz – 18kHz 45Hz – 18kHz
Sensitivity 87dB 90dB 93dB 95dB
Connector XLR/6.35mm/RCA
Mic input level 10mV
Line input/output level 500mV
Input voltage 230V~ 50Hz 115/230V~ 50Hz
Consumption 100W 150W 200W 300W
Fuse 2A 2A 3.15A 3.15A
Dimensions (mm) 225 x 225 x 380 305 x 270 x 480 370 x 320 x 575 435 x 340 x 680
Weight 5.67kg 8.11kg 11.93 17.19kg
