CONTROLS ON THE REAR PANEL
1. Display
2. USB port
3. SD socket
4. MODE: Cycle through USB / LINE / BLUETOOTH
5. EQ: Press to cycle through different music styles
6. Previous/next/ volume control
7. TWS/Repeat mode
8. REC/Playback recorded file
9. Play/Pause
10. Microphone Volume
11. MIC ECHO control
12. Treble control
13. Bass control
14. Line volume control
15. Line / Mic input selector
16. Microphone/Line inputs
17. Line input
18. Mix output
19. Power indicator: lights up when the unit is switched on
20. ON/OFF switch
21. Fuse
22. Mains input
REMOTE CONTROL
ON/OFF button
MODE: Press until the desired operating mode is displayed
MUTE: Sound stop
▶ǁ Play/pause: Press to play a track, press to pause. In FM mode: Search for radio
stations
REC: Press to start, stop and play a recorded le
/CH-: back to the previous track. In FM mode: back to the previous radio station
/CH+: Go to the next track. In FM mode: Go to the next radio station
RPT: Repeat one/repeat all tracks
TWS: Press to switch the unit into TWS pairing mode to connect to a 2nd SLK-A-
TWS box
VOL-: Reduce the volume
Vol+: Increase the volume
EQ: Select among several sound modes (Rock, Pop, Jazz, Classic, Flat)
TRK: Track selection. Press the TRK button, select a track via the number keys (0-9) and press ENTER to conrm
Number buttons: Press the number of the desired track
ENTER: Once you have made your selection, press ENTER to conrm.
RECOMMENDATIONS FOR THE BATTERY IN THE REMOTE CONTROL
This symbol indicates that used batteries should not be disposed of with household waste but deposited in separate
collection points for recycling.
ATTENTION: Danger of explosion if battery is incorrectly placed. Only replace by the same or equivalent type.
WARNING: Do not swallow the battery. Danger of chemical burns.
The supplied remote control contains a button cell. In case of ingestion, it might cause serious internal burns within only 2
hours that might lead to death. Keep new and old batteries out of the reach of children.
If the battery compartment doesn't close properly, stop using the product and keep it out of the reach of children.
If you are in doubt whether the batteries have been swallowed or introduced into any other part of the body, contact im-
mediately a doctor.
CARE
Before cleaning the unit, disconnect it from the mains. Do not use aggressive cleaning agents. Use a clean cloth
to wipe any dust or dirt from the product. We are not liable for damage arising from incorrect handling, impro-
per use or wear and tear. We reserve the right to make technical changes.
EN
