MANUAL - SCAN Laser Systems
24
©Copyright LOTRONIC 2021
128-159 Both ends are zoomed at the same time
160-191 Head and tail were zooming
192-223 Walking drawing
224-255 Turn over drawing
CH16 Auxiliary control of
twist deformation eect
channel
0-255 0-255, the greater the value, the smaller the distortion. [Note:
CH16 can control the degree of twist of the twist eect when
zooming, rotating, moving, and twisting eects]
CH17 Grating selection and
projection amplitude control
0-255 [0-19,grating 1] [20-39,grating 2].....[220-239,grating 12]
[240-255,grating 13] Note: In each paragraph, the larger the
value, the smaller the projection range
TABLE 2 (PATTERN B):
Note: Table 2: CH18-CH34, pattern B’s channel function, except for special instructions, only control the pattern B,
pattern A is not controlled by these 17 channels.
In order to simplify the operation, the functions correspond to pattern A, only special green parts are dierent.
CHANNEL DMX value DESCRIPTION
CH 18 On/o power 0 o working
1-99 Act auto
100-199 Act sound
200-254 retain
255 Pattern A closed light, pattern B output light
CH19 Out of bounds
and pattern size
0-49 Out of bounds
50-99 Re-entry
100-149 Blanking
150-255 Retain
CH20 The distribution
angle of each unit of
the array
0-99 the smaller the value of the segment, the larger the angular distribution
of each unit, the gap is a positive gap
100-199 the smaller the value of the segment, the larger the angle distribution of
each unit, the gap is the negative gap
200-255 retain
CH21 Gallery choose 0-255 Each value corresponds to a pattern, when the value exceeds the num
-
ber of patterns, the system uses the largest number
CH22 Patterns zoom
-
ing
0 No zooming
1-31 Zooming 1
32-63 Zooming 2
64-95 Zooming3
96-127 Zooming4
128-159 Zooming 5
160-191 Zooming 6
192-223 Zooming 7
224-255 Zooming8
CH23 Patterns rotating 0-63 Manual rotating
64-95 Rotating 1
96-127 Rotating 2
128-159 Rotating 3
160-191 Rotating 4
192-223 Rotating 5
