Manual - ROLLING-EYE

www.ibiza-light.com

4 Lens Wheel Rotation

0-127 0-360° rotate

128-191 Forward endless rotation from slow to fast

192-255 Reverse endless rotation from slow to fast

5 Dimmer 0-255 Linear dimmer from dark to bright

6 Strobe

0-9 No Function

10-255 Strobe from slow to fast

7 Red 0-255 Red dimmer from dark to bright

8 Green 0-255 Green dimmer from dark to bright

9 Blue 0-255 Blue dimmer from dark to bright

10 White 0-255 White dimmer from dark to bright

11 Macro Function

0-50 CH1-CH1 Valid

51-150 Random Auto Running

150-255 Sound Control

12 Reset

0-250 None

251-255 Reset after 3s

FIXTURE CLEANING

The cleaning of internal and external optical lenses and/or mirrors must be carried out periodically to optimize

light output. Cleaning frequency depends on the environment in which the 󰊟xture operates: damp, smoky or

particularly dirty surrounding can cause greater accumulation of dirt on the unit’s optics.

• Clean with soft cloth using normal glass cleaning 󰊠uid.

• Always dry the parts carefully.

• Clean the external optics at least every 20 days. Clean the internal optics at least every 30/60 days.

SPECIFICATIONS

Power supply ..................................................................................................................... 100-240V~50/60Hz

Consumption ...........................................................................................................................................120W

Fuse .............................................................................................................................................................2A

Light source ............................................................................................................6 x 12W 4-in-1 CREE led’s

Color temperature...................................................................................................................... White 7000°K

Brightness ........................................................................3200 Lux full color @ 1m/2494 Lux full color @ 3m

Beam angle .................................................................................................................................................. 2°

Protection ..................................................................................................................................................IP20

DMX channels ..............................................................................................................................................12

Movements .........................................................................................................Pan: 540° ; Tilt: 180° (16 bit)

Strobe ...................................................................................................................................... 20 󰊠ashes/sec.

Dimmer ................................................................................................................................................0-100%

Dimensions .......................................................................................................................... 20.5 x 15 x 27cm

Weight ...................................................................................................................................................2.58kg

Electric products must not be put into household waste. Please bring them to a recycling centre. Ask your local authorities or your

dealer about the way to proceed.
