3
https://ibizashop.eu/
OPERATING INSTRUCTIONS
EXPLANATION OF SIGNS
In accordance with the requirements of UK standards
The product is for indoor use only
This marking indicates that this product should not be disposed with other household wastes throughout
the EU. To prevent possible harm to the environment or human health from uncontrolled waste disposal,
recycle it responsibly to promote the sustainable reuse of material resources. To return your used device,
please use the return and collection systems or contact the retailer where the product was purchased. They can
take this product for environmentally safe recycling.
RESTRICTIONS OF USE
This product uses a VHF transmission system that is meant for professional use only.
An ocial license to use this material may be required in some countries. Consult the relevant authorities for
possible requirements.
It may only be used in some countries of the European Union (FR - IT – BE – PT – DE – NL – LU – GR – ES – RO).
USING THE HANDHELD MICROPHONE
1. Open the Battery Compartment: Unscrew the lower part (2) to access the compartment.
2. Insert Batteries: Place 2 AA batteries into the holder, ensuring correct polarity. The negative terminal
should be positioned against the spring.
3. Secure the Cap: Screw the cap back in place.
4. Turn On the Microphone: Slide the switch to the "ON" position (1). The LED indicator (3) will light up
green, and the microphone will automatically connect to your PORT-VHF speaker.
5. Switch Positions: The switch has three positions: OFF, Standby, and ON. For frequent use, leave it in the
Standby position. This prevents the "pop" noise when turning the mic on, but it will use more battery power.
6. Turn Off When Not in Use: Switch off the microphone to save battery life when it’s no longer needed.
7. Replace the batteries: When the LED indicator (3) lights up in red, the batteries are low and should be
replaced.
USING THE HEADSET MICROPHONE
1. Open the Battery Compartment: Open the lower cover (2) to access the compartment.
2. Insert Batteries: Place 2 AA batteries into the compartment, ensuring correct polarity as indicated inside
the compartment.
3. Close the battery compartment.
4. Turn On the Microphone: Slide the switch (1) to the "ON" position. The LED indicator will light up green,
and the microphone will automatically connect to your PORT-VHF speaker.
5. Switch Positions: The switch has three positions: OFF, Standby, and ON. For frequent use, leave it in the
Standby position. This prevents the "pop" noise when turning the mic on, but it will use more battery power.
6. Turn Off When Not in Use: Switch off the microphone to save battery life when it’s no longer needed.
7. Replace the batteries: When the LED indicator (3) lights up in red, the batteries are low and should be
replaced.
RECOMMENDATIONS FOR BATTERIES
This symbol indicates that used batteries should not be disposed of with household waste but deposed correctly in
accordance with your local regulations.
Batteries shall not be exposed to excessive heat such as sunshine, re or the like.
When the internal batteries are not to be used, remove them to avoid damage caused by battery leakage or corrosion.
ATTENTION: Danger of explosion if battery is incorrectly placed. Only replace by the same or equivalent type.
WARNING : Do not swallow the battery. Danger of chemical burns. Keep new and old batteries out of the reach of children.
If the battery compartment doesn't close properly, stop using the product and keep it out of the reach of children.
If you are in doubt whether the batteries have been swallowed or introduced into any other part of the body, contact imme-
diately a doctor.
SPECIFICATIONS
MODEL PORTHAND12 PORTHAND12-2 PORTHEAD12 PORTHEAD12-2
Frequency 203.5MHz 207.5MHz 203.5MHz 207.5MHz
Batteries 2 x AA 1.5V 2 x AA 1.5V 2 x AA 1.5V 2 x AA 1.5V
