PORT-UHF-BT series
6
NO PORT8UHF-BT / PORT10UHF-BT PORT12UHF-BT / PORT15UHF-BT
1 USB port USB port
2 SD slot EQ: Press to cycle through various music styles
3 MODE: Cycle through USB / LINE / BLUETOOTH MODE: Cycle through USB / LINE / BLUETOOTH
4 Mic Volume MIC ECHO control
5 Mic Echo control Microphone Volume
6 UHF microphone Volume UHF microphone ON/OFF/volume controls
7 UHF Mic power ON/RF/AF indicator UHF Mic signal indicator
8 Line in Line input
9 Microphone/Guitar inputs Microphone/Guitar inputs
10 Ipod input AUX (Ipod) input
11 Mix output Mixed output
12 Display Display
13 Short press: Backward/Forward; Long press: re-
duce/increase volume
SD socket
14 Short press: Play/Pause; Long press: REC function Short press: Repeat one/all tracks; Long press: pairing 2 PORT-
UHF-BT boxes with 1 BT source
15 Short press: Repeat one/all tracks; Long press:
enable TWS to pair 2 units of PORT8UHF-BT
REC: Short Press to record, long press to play recorded le
16 Volume Play/Pause
17 VCV control Short press: Backward/Forward; Long press: VOL-/VOL+
18 Treble & Bass control Master volume control
19 Battery level and Charge LED VOX control activated/deactivated
20 Power on or Low Battery LED Treble & Bass control
21 Power Switch Battery Volume and Charge LED
22 DC 12-15V input Power ON (green) and Battery low (red) LED
23 Power Switch
24 15V𝌃 4A power supply input
25 Fuse
26 Mains input
TO PLAY MP3/WMA MUSIC
1. Switch power source to ON. The LED indicator lights up in green.
2. Insert a USB stick (1) or an SD card into the relevant input
3. Select USB via the MODE button (3)
4. Select a title via the or buttons and press ►
TO PLAY LINE IN MUSIC
1. Insert an RCA plug into the LINE IN sockets (8)
2. Insert a wired microphone into MIC INPUT (9)
3. Adjust the MIC VOL (5)
TO USE VOX FUNCTION
When VOX function is enabled, the music level will decrease when somebody talks into one of the microphones. The music
level becomes normal when the user stops talking into the microphone.
To activate this function, switch the VCV switch (19) to on. If you want to disable this function, set this switch to o position
REC FUNCTION
Disconnect the speakerbox from your Bluetooth device. Insert a USB stick or SD card. The speaker will automatically switch
into USB/SD mode. Connect now the speakerbox to your Bluetooth device and start playing your music.
PORT8/10UHF-BT: Long press the REC button to record your voice and the music on the inserted USB stick or SD card.
Press again to stop recording. Keep the REC button pressed to play the recorded le.
PORT12/15UHF-BT: Short press the REC button to record your voice and the music on the inserted USB stick or SD card.
Press again to stop recording. Keep the REC button pressed to play the recorded le.
