PORT12/15UHF-(WH)-MKII

RECOMMENDATIONS FOR THE BATTERY IN THE REMOTE CONTROL

This symbol indicates that used batteries should not be disposed of with household waste but depo-

sited in separate collection points for recycling.

ATTENTION

Danger of explosion if battery is incorrectly placed.

Only replace by the same or equivalent type.

WARNING

Do not swallow the battery. Danger of chemical burns.

The supplied remote control contains a button cell. In case of ingestion, it might cause serious internal burns

within only 2 hours that might lead to death.

Keep new and old batteries out of the reach of children.

If the battery compartment doesn't close properly, stop using the product and keep it out of the reach of

children.

If you are in doubt whether the batteries have been swallowed or introduced into any other part of the body,

contact immediately a doctor.

CARE

Before cleaning the unit, disconnect it from the mains. Do not use aggressive cleaning agents. Use a clean cloth

to wipe any dust or dirt from the product. We are not liable for damage arising from incorrect handling, impro-

per use or wear and tear. We reserve the right to make technical changes.

SPECIFICATIONS

PORT12UHF-MKII PORT15UHF-MKII

Woofer 12"/30cm 15"/38cm

Tweeter 1"/25mm compression driver

Sensitivity 97dB±2dB 101dB±2dB

Max. SPL 109dB 115dB

Impedance 4 Ohm

Freq. range 40-20,000Hz 40-20,000Hz

Built-in battery 12V󰐆 4.5Ah 12V𝌃 7.2Ah

Bluetooth frequency 2402-2480MHz

UHF handheld mic freq. 863MHz

UHF headset mic freq. 865MHz

Power supply 15V󰐆 4A

Consumption 80W

Dimensions 360 x 345 x 560mm

Weight 10.9kg

This marking indicates that this product should not be disposed with other household wastes throughout the EU. To

prevent possible harm to the environment or human health from uncontrolled waste disposal, recycle it responsibly to

promote the sustainable reuse of material resources. To return your used device, please use the return and collection

systems or contact the retailer where the product was purchased. They can take this product for environmental safe

recycling.

THE CE DECLARATION IS AVAILABLE FOR DOWNLOADING ON OUR WEBSITE
