MANUAL - MHBEAM60-FX

Function Value Percent / Setting

Mode

13CH

Mode

21CH

Auto Mode

000-027

028-082

083-112

113-168

169-199

200-239

240-255

No Function

Sound Activity

No Function

Auto Run

No Function

Reset

No Function

13 21

6. FUSE REPLACEMENT

Locate and remove the unit’s power cord. Once the cord has been removed located the fuse holder inside the

power socket. Insert a 󰊠at-head screw driver into the power socket and gently pry out the fuse holder. Remove

the bad fuse and replace with a new one. The fuse holder has a built-in socket for a spare fuse. Be sure not to

confuse the spare fuse with the active fuse.

Warning: If after replacing the fuse you continue to blow fuses, STOP using the unit. Contact customer support

for further instructions. Continuing to use the unit may cause serious damage.

7. CLEANING

Fixture Cleaning: Due to fog residue, smoke, and dust cleaning the internal and external lenses should be car-

ried out periodically to optimize light output.

1. Use normal glass cleaner and a soft cloth to wipe down the outer case.

2. Use a brush to clean the cooling vents and fan grill.

3. Clean the external optics with a glass cleaner and a soft cloth every 20 days.

4. Clean the internal optics with a glass cleaner and a soft cloth every 30-60 days.

5. Always be sure to dry all parts completely before plugging the unit back in.

8. TROUBLE SHOOTING

Listed below is a problem that you may encounter, with a solution.

No light output from the unit;

1. Be sure the fuse has not blown. The fuse is located on the rear panel inside the power socket. See Fuse Re-

placement.

2. Be sure the fuse holder is completely and properly seated.

Auto Sensing Voltage: This 󰊟xture contains an automatic voltage switch, which will auto sense the voltage

when it is plugged into a power source.

9. SPECIFICATIONS:

Voltage: ....................................................................................................................................... AC100V-240V, 50/60 Hz

Total power:................................................................................................................................................................ 80W

Light source: .............................................................................2pcs 30W RGBW 4in1 LED, 2*12pcs 5050 RGB 3in1 LED

Control mode: ...........................................................................................Auto run, sound activated, DMX, master-slave

DMX Channel: .................................................................................................................................................13CH/21CH

Light e󰊞ect: ................................................................Wash light, color jumping, color gradual change, strobe, dimming

Optics system: .......................................................................................................................High e󰊡ciency 8°optic lens

Movement: ............................................................................................................ Pan In󰊟nite rotation, Tilt 185° rotation

Dimming: .........................................................................................................................................................0% - 100%

Strobe: ...........................................................................................................................................1-20 times per second

Display: .......................................................................................................................................................... LED Display

Cooling system ................................................................................................................................................. Fan cooled

Dimensions: ......................................................................................................................................270 x 170 x 310mm

Weight: ..................................................................................................................................................................3.59 kg

Please Note: Speci󰊟cations and improvements in the design of this unit and this manual are subject to change

without any prior written notice.

Electric products must not be put into household waste. Please bring them to a recycling

centre. Ask your local authorities or your dealer about the way to proceed.
