MANUAL - LZR Laser Show Systems
6
©Copyright LOTRONIC 2019
Button Function Description
ON/OFF In REMOTE mode, to turn ON / OFF laser. In any stand-alone mode, except
SLA mode, pressing 2 seconds to activate REMOTE mode.
AUTO AUTO running show 1/2
MUSIC SOUND activated show 1/2. The blue music LED indicator is ashing when
a sound signal is detected.
COLOR CHANGING Cycle through Programmed Colour
A B
C
PATTERN CHANGING To show and change patterns
0
-/--
9
FIXED PATTERN Choose favourite PATTERN from 1 to 128.
PATTERN REPEAT Last PATTERN and current PATTERN cycle repeating
PATTERN ID Choose PATTERN with 1/2/3 digital ID
DMX PROTOCOL
CHANNEL DMX CONTROL
CH 1
CONTROL
MODE
000-063
063-127
128-191
192-255
BLACK OUT
AUTO SHOW
MUSIC SHOW
DMX MODE
CH2 GOBOS 0-255 Split 32 patterns
CH3
ZOOM
0-127
128-169
170-209
210-255
100%-5%
Zoom out mode
Zoom in mode
Zoom out and Zoom in mode
CH4
LEFT RIGHT
TURN
000-127
128-255
192-255
0-359 Degree
Clockwise Mode
Anticlockwise Mode
CH5
UP DOWN TURN
000-127
128-191
192-255
0-359 Degree
Clockwise Mode
Anticlockwise Mode
CH6
ROTATE
000-127
128-191
128-255
0-359 Degree
Clockwise Mode
Anticlockwise Mode
CH7
LEFT RIGHT
MOVE
000-127
128-191
128-255
Left Right position, total 128 position
Clockwise Move Mode
Anticlockwise Move Mode
CH 8
UP DOWN MOVE
000-127
128-191
128-255
Up Down position, total 128 position
Clockwise Move Mode
Anticlockwise Move Mode
CH9
COLOR
000-015
016-063
064-149
150-255
Original colour
Static colour
JUMP COLOR
LOOP COLOR
If single colour is set, there will be no
eect
IMPORTANT NOTE: Electric products must not be put into household waste. Please bring them to a recycling centre. Ask your local au-
thorities or your dealer about the way to proceed.
