MANUAL - GRAFFIK600

©Copyright LOTRONIC 2024

2. Activate the BT search function on your cell phone to search for the BT device. Please refer to the user manu-

al for details

3. Select GRAFFIK600 in the list of found devices. Enter the password "0000" if required.

4. Shortly press the PLAY/PAUSE button ▶ to play or pause the music. Shortly press the “ ” or “” button to

select the previous or next track.

AUX MODE:

Press the MODE button on the unit or the remote control until LINE is selected. Play the music of the device

connected to the AUX input via a 3.5mm Jack.

USB MODE:

1. Insert a USB stick and press the MODE button to select “USB” mode. The unit will automatically read and

play the music on the connected device.

2. Press “▶” button shortly to pause or play.

3. Shortly press “” button to go to the previous song.

4. Shortly press “” button to go to the next song.

5. Press the Repeat button (13) on the remote control. The display will show "ONE" and the track will be

played continuously. Press twice and the display will show "ALL". All songs on the USB will be played contin-

uously.

TWS MODE

1. Place the two TWS speakers near each other (the distance should not exceed 10 meters).

2. Power on the two speakers, both speakers must be in Bluetooth mode. Press and hold for about 5 seconds

the TWS button on one of the speakers that will be the master speaker. The TWS connection will be built up.

3. In TWS mode, press and hold TWS button for about 5 seconds on either speaker or power off the speaker to

exit the TWS mode.

VOICE RECORDING

The unit can record voice from the microphone on a USB stick. It will create automatically a folder called 'Re-

cord' on the USB stick where it will store all log 󰊟les.

1. Switch on the unit

2. Insert a USB stick into the socket.

3. Select USB mode via the MODE button on the unit or the remote control.

4. Press the REC button on the unit or the remote control to start recording.

5. Press REC again to stop recording. The unit will play automatically the recorded file.

Note: You can record only voice. During recording, some controls are deactivated; They will resume their normal function when

recording is stopped.

SPECIFICATIONS

Input voltage ................................................................................................................... 100-240V~ 50/60Hz

Battery ...................................................................................................................... Lithium 18.5V 4000mAh

USB output voltage .............................................................................................................................5V 1.5A

Consumption ..........................................................................................................................................196W

Bluetooth frequency band....................................................................................................... 2402-2480MHz

Max. RF emission value of BT. ...........................................................................................................0.19dBm

Dimensions ..................................................................................................................... 347 x 319 x 728mm

Weight .................................................................................................................................................. 15.2kg
