MANUAL - FLASH-COLOR-STROBE

©Copyright LOTRONIC 2023

• Disconnect mains power before fuse replacement or servicing.

• Make sure there are no in󰊠ammable materials close to the unit during operation.

• In the event of serious operating problem, stop using the unit immediately.

• The light sources of the light e󰊞ects are not replaceable. If a light source is faulty, the light e󰊞ect must be dis-

carded.

• Do not touch any wires during operation as high voltage might be causing electric shock.

• The light source contained in this luminaire shall only be replaced by the manufacturer or his service agent or

a similar quali󰊟ed person.

• The product is for decorative purposes only and not suitable as a household room illumination.

DISCONNECT DEVICE

Where the MAINS plug or an appliance coupler is used as the disconnect device, the disconnect device shall

remain readily operable.

INSTALLATION

The unit should be mounted via its screw holes on the bracket. Always ensure that the unit is 󰊟rmly 󰊟xed to

avoid vibration and slipping while operating. Always ensure that the structure to which you are attaching the

unit is secure and is able to support a weight of 10 times of the unit’s weight.

The installation must always be secured with a secondary safety attachment, e.g. an appropriate safety rope.

Never stand directly below the device when mounting, removing or servicing the 󰊟xture.

DMX CONNECTION

Connect an XLR cable to the male 3-pin XLR output of your controller and the other side to the female 3-pin XLR

input of the light.You can chain multiple lights together through serial linking

The cable needed should be two core, screened cable with XLR input and output connectors.

MENU BUTTONS

You can set the operating mode of the unit via the 4 function buttons . Press the MENU button to display the

di󰊞erent functions (see table below for a detailed description of the functions). Use the UP and DOWN arrow

buttons to make your selection. Once you have chosen your desired function, press the ENTER button to con󰊟rm

the change.

Mode Programming Description

Auto mode Auto Sp 1-10 Auto Speed 1-10 (slow-> fast) In Auto mode, all e󰊞ects run randomly

St 0-9 (slow-> fast) (stroboscopic)

DMX mode Addr 6 CH A001-A507 Each channel mode has a separate

address. Plug in the console and auto-

matically enter DMX mode

9 CH A001-A504

64CH A001-A449

112C A001-A401

Show Shou Sh 1-12 Program Show 1-12 (built-in 12 combined e󰊞ects)

Sp 1-10 Program Speed 1-10 (slow-> fast)

St 0-9 Program Flash 0-9 (slow-> fast)

Sound

Mode

Soud Sen1-9 Voice control mode, adjustable sensitivity

Slave SLAV Slave Slave (slave, automatically identify master)

Edit color Colo R000-255 Red (0-100%) red adjustment

G000-255 Green (0-100%) Green Adjustment

B000-255 Blue (0-100%) blue adjustment

U000-255 W (0-100%) White Light Adjustment

St. 0-9 LED Strobe (slow-> fast) (stroboscopic)

Static colors StAt CL01-CL37 Static color (37 static colors available)

St0-9 LED Strobe (slow-> fast) (stroboscopic)
