Often, the set up for Master-Slave and Stand-alone operation requires that the 󰊟rst 󰊟xture in the chain be initial-

ized for this purpose via either settings in the control panel or DIP-switches. Secondarily, the 󰊟xtures that follow

may also require a slave setting. Please consult the '' Operating Instructions» section in this manual for complete

instructions for this type of setup and con󰊟guration.

NAVIGATION THROUGH THE CONTROL PANEL

Access control panel functions using the four panel buttons located directly underneath the LCD Display..

Button Function

MENU Used to access the menu or to return to a previous menu option

UP Scrolls through menu options in ascending order

DOWN Scrolls through menu options in descending order

ENTER Used to select and store the current menu or option within a menu

When a menu function is selected, the display will show immediately the 󰊟rst available option for the selected

menu function. To select a menu item, press <ENTER>.

MENU MAP

Display Description

Addr A001---A512 address code

CHnd 13CH or 15CH mode

SLnd Auto : Host self-running mode

Soun: Host self-running mode

SL 1: DMX Control Mode

SL 2: Slave Mode

SHnd SH 0 : No e󰊞ect

SH 1: E󰊞ect 1

SH 2: E󰊞ect 2

SH 3: E󰊞ect 3

SEnS Sound sensitivity (0-99)

bLAnd bLAc : No function

Auto: no dmx signal for Auto

Soun: no dmx signal for Sound

HoLd: keep history for dmx

LEd ON/OFF display backlight

dISP YES/NO Reverse display

rPAN YES/NO Horizontal motor inversion

rTiL YES,/NO Vertical motor inversion

Reset Factory system reset

DMX CHANNEL TABLE: SEE AT THE END OF THE MANUAL

FIXTURE CLEANING

The cleaning of internal and external optical lenses and/or mirrors must be carried out periodically to optimize

light output. Cleaning frequency depends on the environment in which the 󰊟xture operates: damp, smoky or

particularly dirty surrounding can cause greater accumulation of dirt on the unit’s optics.

• Clean with soft cloth using normal glass cleaning 󰊠uid.

• Always dry the parts carefully.

• Clean the external optics at least every 20 days. Clean the internal optics at least every 30/60 days.

SPECIFICATIONS

Power supply .......................................................................................................................90-240V~50/60Hz

Consumption ...........................................................................................................................................150W
