INSTALLING THE BATTERIES IN THE REMOTE CONTROL

Remove the battery cover from the back of the remote control as shown and insert 2x

AAA size batteries ensuring correct polarity

RECOMMENDATIONS FOR BATTERIES

This symbol indicates that used batteries should not be disposed of with household waste but deposed correctly in

accordance with your local regulations.

Batteries shall not be exposed to excessive heat such as sunshine, 󰊟re or the like.

When the internal batteries are not to be used, remove them to avoid damage caused by battery leakage or corrosion.

ATTENTION: Danger of explosion if battery is incorrectly placed. Only replace by the same or equivalent type.

WARNING : Do not swallow the battery. Danger of chemical burns. Keep new and old batteries out of the reach of children.

If the battery compartment doesn't close properly, stop using the product and keep it out of the reach of children.

If you are in doubt whether the batteries have been swallowed or introduced into any other part of the body, contact imme-

diately a doctor.

TROUBLESHOOTING

Problem Solution

Automatic shut down when

turned on

Low battery. Fully charge the battery before use

The player automatically

shuts down or restarts

Low battery. Fully charge the battery before use

The charging light is not on,

no charging

Make sure the charging cable is plugged in properly. Check if the cable is dam-

aged. Please use a 5V 2A charger to charge the device

No sound from Bluetooth Make sure that Bluetooth is paired correctly and the Bluetooth device is playing

and the volume is not at the minimum

No sound from USB/TF Check if the TF card is inserted in the correct direction and in place

Check if the USB stick is inserted and in good contact

Check if the music format on the TF/USB is correct (supports mainly MP3 and

WMA audio 󰊟les

Check the volume level

Recording doesn't work Check if there is space on the TF card or USB stick. Delete some 󰊟les to reserve

storage space

Recording should be done in TF, USB mode, insert a wired microphone or turn

on a wireless microphone.

SPECIFICATIONS

Woofers ..........................................................................................................................................2 x 3"/8cm

Input voltage via USB-C ................................................................................................................5.0V󰐆 2.0A

Battery ..................................................................................................................... Lithium 3,7V󰐆 4500mAh

Run time on battery ..............................................................................................3-6h depending on volume

Freq. response............................................................................................................................75Hz – 12kHz

S/N ratio ............................................................................................................................................... >80dB

FM band ...................................................................................................................................87.5 – 108MHz

BT freq. band .......................................................................................................................... 2402-2480MHz

Max. RF emission of BT ..................................................................................................................... 1.36dBm

Dimensions ..................................................................................................................... 368 x 139 x 183mm

Weight .................................................................................................................................................. 2.05kg
