Standard accessories
Important Safety Instructions ............................. 1 pc.
Safety wire ×1 Spring washer ×1 Flat washer ×1
Other items that are needed (not included)
Mounting screws
Installation method
Recommended
screw
*1
Minimum pull-out
strength
*2
When mounting with WV-QCL102-W
Mount bracket: Approx. 240 g {0.53 lbs}
Camera: Approx. 290 g {0.64 lbs}
M6 × 16 mm*
3
{5/8
inches}
x
4pcs.
562 N {126
lbf}
Screw required to secure the safety wire
M4 × 16 mm*
3
{5/8
inches}
x
1pc.
24.5 N {5.5
lbf}
*1 Select screws according to the material of the location that the camera will be mounted to.
In this case, wood screws and nails should not be used.
*2 This value indicates the minimum pull-out strength required value per screw. For information about the
minimum pull-out strength, refer to our technical information website <Control No.: C0120>.
*3 The screw length is an example when installing the camera on a robust installation surface with a
thickness of 20mm {25/32inches} or more.
Ethernet cable with RJ45 plug (category 5e or better, straight, all 4 pairs (8pins), less than 100m {328
feet})
As necessary, audio input cable, audio output cable
Hexagonal wrench (3 mm {1/8 inches})
Optional accessories
The latest information → Technical information website “Accessory Selector”
<Control No.: C0501>
Troubleshooting
Before requesting service, refer to “Troubleshooting” of Web Guide. Then, confirm the trouble.
8
