Living 6
Exsis I/T - 01/23-1 - EHG-0027-02EN 79
6.7.1 Storage compartment in double floor
Depending on the equipment, a carpet segment will have to be put aside
to gain access to the storage compartments.
The storage compartments are accessible through lids in the living area.
The disposition of the storage compartments is dependent on the model.
Fig. 59 Floor storage compartment
cover (handle recessed)
Fig. 60 Floor storage compartment
cover (handle swung out)
◼ If necessary, lay carpet segment aside.
◼ Push one side of the grip plate (Fig. 59,1) downwards. The handle
(Fig. 60,1) swivels upwards.
◼ Remove the cover (Fig. 60,2) upwards.
Close the lid and recess the handle as soon as possible. Otherwise,
there will be danger of tripping due to the open floor storage compart-
ment or the protruding handle.
Do not bend the carpet segments.
Do not leave the carpet segments laying in the room. Danger of trip-
ping!
◼ Insert the cover (Fig. 60,2) in the frame on the floor.
◼ Swivel handle downwards.
Opening:
Closing:
