Living 6
Exsis I/T - 01/23-1 - EHG-0027-02EN 75
Fig. 53 Skylight (pleated blind
closed)
◼ Reach into the recessed grip of the pleated blind and pull the pleated
blind to the desired position.
◼ Reach into the recessed grip of the insect screen and pull the insect
screen to the desired position.
The pleated blind and the insect screen can be infinitely adjusted inde-
pendently of each other.
6.5.3 Wind-up skylight
Fig. 54 Wind-up skylight
Fig. 55 Hand crank
The wind-up skylight can be opened using the hand crank. The hand crank
is folded out (Fig. 55,2) for opening and closing. The hand crank is folded in
(Fig. 55,1) when in resting position.
◼ Rotate the hand crank (Fig. 54,2) until a resistance can be felt.
◼ Rotate the hand crank until the wind-up skylight is closed. The wind-up
skylight can be locked after rotating two or three more times.
◼ Check the locking mechanism. To do so, press your hand against the
acrylic glass.
Closing/opening the shade:
Closing/opening the insect
screen:
Opening:
Closing:
