Living 6
Exsis I/T - 01/23-1 - EHG-0027-02EN 69
6.4.1 Front passenger's window
Fig. 43 Front passenger's window
◼ Unfold the handle (Fig. 43,1).
◼ Push or pull forward the window section into the required position.
◼ Close the window as far as possible and let the handle lock in place.
6.4.2 Hinged window with automatic hinges
Open the window completely, to release the lock. If the locking device is
not released and the window is closed nevertheless, there is the danger
of the window breaking due to the massive counter-pressure.
When opening the hinged windows, ensure that there are no torsional
forces. Open and close the hinged windows evenly.
The catch lever is fitted with a safety knob. When operating the catch
lever, always press the safety knob.
Fig. 44 Catch lever ("closed" posi-
tion)
Fig. 45 Hinged window with auto-
matic hinge
◼ Press the safety knob (Fig. 44,1) and keep it pressed.
◼ Turn the catch lever (Fig. 44,2) a quarter turn towards the centre of the
window.
◼ Open the hinged window to the desired latched position. The automatic
hinge (Fig. 45,1) locks in place automatically.
The hinged window remains locked in the required position.
Opening:
Closing:
Opening:
