3 Before the journey
28 Exsis I/T - 01/23-1 - EHG-0027-02EN
The technically permissible maximum laden mass and the technically
permissible maximum laden mass on the axle must not be exceeded.
Especially when stowing or attaching heavy accessories or heavily laden
accessories (such as motorcycle carriers or bicycle carriers) at the rear,
the mass on the axle must be checked and complied with. If you are not
sure whether the loaded vehicle complies with the technically permissi-
ble maximum laden mass and the technically permissible maximum
laden mass on the axle, you can weigh/check the vehicle on public
scales or have it weighed by certain dealers.
For individual models, a maximum load is specified by the body manu-
facturer for cabinets, drawers, storage compartments, or other storage
spaces. This maximum load can be seen on the stickers attached on site
and must be observed at all times. However, the technically permissible
maximum laden mass and the technically permissible maximum laden
mass on the axle must not be exceeded under any circumstances. For
this reason, please note that the stated maximum load may not be fully
utilized if this would result in the exceedance of the technically permissi-
ble maximum laden mass or technically permissible maximum laden
mass on the axle.
Further information on correct loading can be found in the sections
"Technically permissible maximum laden mass" (page 22), "Technically
permissible maximum laden mass on the axle (mass on the axle)"
(page 28) and "Rear garage/rear storage space" (page 32).
To distribute the load correctly, you will need a scale, a tape measure, a cal-
culator and some time.
Two simple formulas are needed to calculate the effect of the weight of the
load on the axles:
A x G : R = weight on the rear axle
Weight on the rear axle – G = weight on the front axle
A = distance between storage space and front axle in cm
G = weight of the load in the storage space in kg
R = wheelbase of the vehicle (distance between axles) in cm
Measure the external distances horizontally from the centre of the front
wheel to the centre of the storage space or to the centre of the back
wheel.
The technically permissible maximum laden mass on the axle or group of
axles (hereafter referred to as mass on the axle) refers to the vehicle- and
axle-specific load that may be transferred from the wheels of an axle or
group of axles to the road surface. The mass on the axle is a value specified
by the manufacturer that, for safety reasons, the vehicle must never exceed,
even when loaded. You will find information on the mass on the axle of your
vehicle in the registration papers and on the body manufacturer's nameplate
in the vehicle.
Formulas
Explanation
Technically permissible
maximum laden mass on
the axle (mass on the
axle)
