3 Before the journey
26 Exsis I/T - 01/23-1 - EHG-0027-02EN
Mass in kg to be
calculated
Calculation
Example for calculating
the payload
Technically permissible maximum laden
mass according to vehicle documents
3500
Actual vehicle mass including standard
equipment according to the vehicle docu-
ments
- 3070
This results in a permissible payload of
430
Flat-rate value of 10 kg per meter vehicle
length (in the example: 7.00 m)
-70
Conventional load e.g.: 3 persons each
weighing 75 kg
- 225
Optional equipment and accessories
- 40
For the personal pay-mass this results
in
= 95
The pay-mass is calculated based on the regulation (EC) no. 1230/2012.
The calculation of the vehicle load capacity from the difference between the
technically permissible maximum laden mass and the actual vehicle mass
specified by the manufacturer is however only a theoretical value.
Only if the vehicle is weighed on a public scale with filled tanks (fuel and wa-
ter), filled gas bottles and complete optional equipment (and accessories)
can the actual vehicle load capacity be determined.
To do this, proceed as follows:
◼ First only drive the vehicle on to the weighbridge with the front wheels
and have it weighed.
◼ Then drive the vehicle on to the weighbridge with the back wheels and
have it weighed.
The individual values give the current masses on the axles. These are im-
portant for the correct loading of the vehicle (see section 3.2.3). The sum of
these values is the current weight of the vehicle.
The actual vehicle load capacity is the difference between the technically
permissible maximum laden mass and the weighed vehicle weight.
This can be used to determine the weight that remains for the personal
equipment:
◼ Determine the weight of the passengers and subtract it from the value
for the actual vehicle load capacity.
The result is the weight that is permitted for the actual load of the personal
equipment.
3.2.3 Load securing and load distribution
For safety reasons, never exceed the technically permissible maxi-
mum laden mass.
Distribute the load evenly on the left and right sides of the vehicle.
Distribute the load evenly on both axles. Observe the technically per-
missible maximum laden mass on the axle specified in the vehicle
documents. Observe the permissible load-carrying capacity of the
tyres (see chapter 13).
