Customer service and maintenance 12
Exsis I/T - 01/23-1 - EHG-0027-02EN 199
Fig. 161 Front headlight (rear side)
Fig. 162 Bulb (low beam/main beam)
◼ Switch ignition and lighting off.
◼ Open the bonnet (see chapter 4).
◼ Turn the housing cover (Fig. 161,1) in an anticlockwise direction and
remove.
◼ Turn the holder (Fig. 162,1) with the lamp in an anticlockwise direction
and take it out of the lamp housing.
◼ Pull the bulb out of the holder.
◼ Insert the new bulb (H7 - 12 V/55 W) into the holder such that the socket
plate fits into the recess of the holder.
◼ Insert the holder (Fig. 162,1) with bulb into the lamp housing and tighten
in a clockwise direction. The holder engages audibly.
◼ Place the housing cover (Fig. 161,1) and tighten in a clockwise direction.
◼ Close the bonnet.
Fig. 163 Curve light/fog light
Fig. 164 Curve light/fog light (from be-
low)
◼ Reach behind the combined headlight for curve light/fog light (Fig. 163),
turn holder (Fig. 164,1) with the bulb in an anticlockwise direction and
take it out of the headlight housing.
◼ Pull the bulb out of the holder.
◼ Insert the new bulb (H7, 12 V/55 W) into the holder such that the socket
plate fits into the recess of the holder. While doing this, do not touch the
bulb with bare fingers.
◼ Insert the holder (Fig. 164,1) with the bulb from behind into the headlight
housing and turn in a clockwise direction. The holder engages audibly.
Low beam/main beam
(Fig. 160,2)
Curve light/
fog light (Fig. 159,2)
