Electrical system 8
Exsis I/T - 01/23-1 - EHG-0027-02EN 123
8.7.2 Battery voltage display
The panel shows the battery voltage of the entire battery system. If the
vehicle has a HYMER Smart Battery System (optional equipment), a fur-
ther display panel is installed. You can read the exact voltage values on
this additional display panel.
The battery voltage will be displayed for approx. 20 seconds after it has
been called up.
Use the rotary knob (Fig. 105,5) for reading the voltage of the living area
battery as well as that of the starter battery. The voltage is displayed on the
indicator scale for battery voltage (Fig. 105,1).
◼ Turn the rotary knob (Fig. 105,5) until the symbol for the desired battery
lights up.
Symbol
Signification
Living area battery voltage is displayed (Fig. 105,9)
Starter battery voltage is displayed (Fig. 105,6)
◼ Read the voltage from the indicator scale for battery voltage
(Fig. 105,1).
The following tables will help you to correctly interpret the battery voltage
display.
Battery voltage
(values during
operation)
Mobile operation
(vehicle moving,
no 230 V connec-
tion)
Battery operation
(vehicle station-
ary, no 230 V con-
nection)
Power operation
(vehicle station-
ary, 230 V con-
nection)
Notes regarding the bat-
tery voltage
Less than 11 V
Danger of total dis-
charge
No charging via the
alternator
If appliances are
switched off: Bat-
tery flat
No charging via the
transformer/rectifier
12 V power supply
overload
If appliances are
switched on: Bat-
tery overload
12 V power supply
overload
11.5 V to 13 V
No charging via the
alternator
1)
Normal range
No charging via the
transformer/recti-
fier
1)
12 V power supply
overload
1)
12 V power supply
overload
1)
13.5 V or more
Battery being
charged
Occurs only briefly
after charging
Battery being
charged
1)
If the voltage does not exceed this range for several hours.
Values for off-load voltage
Charging condition of the battery
Less than 12 V
Totally discharged
12.2 V
25 %
12.3 V
50 %
More than 12.8 V
100 %
Displays:
