6 Living
98 B-MC I/T - 01/23-1 - EHG-0016-03EN
6.11 TV unit
Before commencing the journey, return the flat screen and the screen
holder into the initial position and secure them.
For version with HYMER Smart Multimedia system:
When a television is used in conjunction with the special feature "HY-
MER Smart Multimedia system", the television must have the following
data in order to guarantee faultless operation:
TV power consumption in stand-by mode < 0.5 W
TV power consumption in operation ≥ 15 W (max. 30 W)
Headphones output (3.5-mm-jack) on the TV should have a voltage
of 1.2 V
SS
at one third maximum volume
The flat screen is secured on the side by a guide rail (Fig. 95,1).
Fig. 95 Flat screen
◼ Press the release button (Fig. 95,2).
◼ Pull flat screen out of the guide rail (Fig. 95,1), into the desired position.
◼ Take hold of the flat screen at the top and bottom edge and tilt it as desi-
red.
◼ Take hold of the flat screen at the top and bottom edge and move it into
the straight position.
◼ Push flat screen back until it engages in the guide rail (Fig. 95,1) on the
side.
Flat screen, integrable
Positioning the flat screen:
Bringing the flat screen into
the initial position:
