Living 6
B-MC I/T - 01/23-1 - EHG-0016-03EN 89
6.5.4 Skylight with fan
Do not switch on the fan without a fly screen. Do not put your hands or
fingers into the fan while it is running. Switch off the power supply be-
fore cleaning work.
A 4 A fuse (Fig. 80,4) protects the fan motor against overloading. If an
overload has occurred: Determine and correct the cause (e.g. dirty fan)
before replacing the fuse.
A contact switch switches off the fan when the skylight is closed. The fan
only runs when the skylight is opened a few centimetres.
To obtain optimum fan effect: Close all other skylights and open at least
one window.
Also read the manufacturer's instruction manual.
Fig. 80 Skylight with fan
◼ Turn the rotary handle (Fig. 80,2) until the desired opening angle is
reached.
◼ Turn the rotary handle until the skylight is closed.
◼ Set the flip switch (Fig. 80,3) to "Aerate" (air flows from the outside in-
wards) or "Vent" (air flows from the inside outwards).
◼ Set flip switch (Fig. 80,3) to the central position.
◼ Turn the rotary switch (Fig. 80,5) to the desired setting:
0 = off
1 = slow
2 = medium
3 = fast
◼ Turn the thermostat (Fig. 80,1) as far as possible in the "blue" direction.
◼ When the desired temperature is reached: Turn the thermostat in the
"red" direction until the fan switches off. When the temperature rises
again, the fan switches back on again.
◼ Turn the black cover (Fig. 80,4) counterclockwise a quarter of a turn.
◼ Remove the cover by pulling it carefully downwards. The fuse is located
on the rear side of the cover.
◼ Check if the wire inside the fuse is torn.
Opening the skylight:
Closing the skylight:
Aerating/venting:
Switching off the fan:
Adjusting the fan speed:
Adjusting the temperature:
Replacing fuse:
