6 Living
86 B-MC I/T - 01/23-1 - EHG-0016-03EN
Fig. 72 Skylight (closed)
Fig. 73 Crank
◼ Unfold the crank (Fig. 73,1) and turn it in a clockwise direction until the
skylight has reached the desired position.
◼ Fold in the crank.
Only turn the crank until you feel a slight resistance. At that point, you
will have reached the maximum opening angle of the skylight.
◼ Unfold the crank (Fig. 73,1) and turn it in an anticlockwise direction until
the skylight is closed.
◼ Fold in the crank.
Fig. 74 Skylight (pleated blind
closed)
◼ Reach into the recessed grip of the pleated blind and pull the pleated
blind to the desired position.
◼ Reach into the recessed grip of the insect screen and pull the insect
screen to the desired position.
The pleated blind and the insect screen can be infinitely adjusted inde-
pendently of each other.
Opening the skylight:
Closing the skylight:
Closing/opening the shade:
Closing/opening the insect
screen:
