Pitching the Motorcaravan 5
B-MC I/T - 01/23-1 - EHG-0016-03EN 67
The steady legs system can be operated via the supplied Bluetooth manual
control unit or via the HLC
®
Smart App on a smartphone.
If the steady legs system does not recognise the manual control unit or
smartphone via Bluetooth, connect as follows:
◼ Make sure that the conditions for extending mentioned above have been
created.
◼ Engage a gear. A signal tone sounds.
◼ Pair the manual control unit or smartphone with the steady legs system
within 5 seconds.
◼ For vehicles with automatic transmission: engage gear P.
For vehicles with manual transmission: engage neutral.
The hydraulic steady legs system has two operating modes:
⚫ Manual mode
⚫ Automatic mode (always activated after switching on)
In Automatic mode, the vehicle is automatically aligned horizontally both
lengthways and crossways.
Both modes are controlled via the control unit.
1 "Manual mode" LED
2 "Inclination" LEDs (red, 4 pcs., indi-
cate the side on which the vehicle is
inclined)
3 "Position ok" LED (green)
4 "Retract" button
5 "Extend" button
6 "On/Off/Mode" button
7 "Next" button (selects the next pair
of steady legs)
8 "Steady leg" LEDs (green, 4 pcs.,
flash during movement)
9 "Automatic mode" LED
Fig. 47 Control unit (hydraulic steady
legs)
If the vehicle's tilt is too great, the corresponding red "Inclination" LED flas-
hes (Fig. 47,2). Select a suitable location, or operate the steady legs manu-
ally at your own risk.
If when being extended a steady leg reaches its maximum length due to a
depression in the ground, the "Manual mode" (Fig. 47,1) and "Automatic
mode" LEDs flash (Fig. 47,9) three times. If this happens, retract the steady
legs, place suitable supports under the affected steady leg and repeat the
procedure.
◼ Press the "On/Off/Mode" (Fig. 47,6) button for longer than 1 second. Af-
ter switching on, a signal tone sounds and the "Automatic mode" LED
(Fig. 47,9) lights up.
If it is not used, the steady legs system deactivates itself automatically after
30 minutes.
◼ Press the "On/Off/Mode" button (Fig. 47,6) briefly. The mode changes
between Manual and Automatic. The corresponding LED (Fig. 47,1 or
Fig. 47,9) lights up.
◼ Press any button.
Operating options
Operating modes
Switching on/off:
Changing mode:
Stopping every movement:
