During the journey 4
B-MC I/T - 01/23-1 - EHG-0016-03EN 47
4.3 Driving speed
The vehicle is equipped with a powerful engine. This means there are
sufficient reserves in difficult traffic situations. This high power enables
a high maximum speed and requires above-average driving ability.
The vehicle provides a large contact surface for wind. A sudden cross-
wind can be especially dangerous.
Uneven or one-sided loading affects road performance.
Driving on unknown streets, you may encounter hazardous road con-
ditions and unexpected driving situations. Therefore, in the interest of
safety, make sure your driving speed is appropriate to any given dri-
ving situation and environment.
Adhere to the national legal speed limits.
4.4 Air suspension
Make sure that no persons are staying underneath the vehicle or
between the wheels when the vehicle is lowered.
Do not overload the vehicle (do not exceed the axle load nor the permis-
sible gross weight).
Make sure that it is possible to lower the vehicle can be freely even after
a longer stationary period.
Before setting of, check the system pressure at the pressure gauge. The
system pressure shall be within a range from 1 to 6 bar. If required, in-
crease the pressure or decrease the pressure.
When using snow chains: make sure that there is sufficient free space
for the snow chains.
In addition to the standard equipment of the vehicle with steel springs, two
bellows are installed on the rear axle. With that, the vehicle can be lifted se-
veral centimetres.
1 On/Off button
2 Bleeding pin
3 Pressure gauge
Fig. 15 Electrical control unit
◼ Press On/Off button (Fig. 15,1) on the electrical control unit. Fill the sys-
tem with an external compressor through a valve (on the left side of the
left-hand vehicle seat console).
1-circuit system
Raising the vehicle:
