3 Before the journey
24 B-MC I/T - 01/23-1 - EHG-0016-03EN
The mass in running order and the actual vehicle mass are specified by the
manufacturer in the vehicle documents.
To determine the remaining payload capacity, it is important that you know
the real weighed mass of your vehicle. When your vehicle is completed, we
therefore determine the real weight of your vehicle for the first time by
weighing it at the end of the belt. This includes the mass in running order
plus the weight of all ordered and factory-fitted special equipment.
Using this real weighed mass, you can calculate the remaining payload
capacity for luggage or other accessories.
Example:
Maximum permissible gross weight - real weighed mass - mass of the pas-
sengers = remaining payload capacity
3500 kg - 3000 kg - 225 kg (3 x 75 kg) = 275 kg
Please note that the factory calculation of the remaining payload capa-
city assumes a flat rate of 75 kg per seat for the mass of the driver (in-
cluded in the real weighed mass) and the mass of the passengers. Due
to differing body weights, the real remaining payload capacity of your ve-
hicle may be affected.
The real mass of your vehicle weighed at the factory may vary slightly in
retrospect due to weather conditions and, for example, the associated
absorption or release of moisture. Any further subsequent modification
of your vehicle, e.g. through the additional installation of accessories at
the dealer's or other extensions and/or conversions, will additionally in-
fluence the notified real weighed mass of the vehicle and consequently
also the remaining payload capacity. It is the responsibility of the dealer
after collection from the factory and until delivery, and subsequently your
responsibility from the time of handover by the dealer, to prevent the ma-
ximum permissible gross weight from being exceeded. If you are not
sure whether the laden vehicle complies with the technically permissible
maximum laden mass, there is the possibility of weighing/checking the
vehicle on public scales or at individual dealers.
We will inform your dealer of the actual mass of your vehicle weighed by
us at the factory and the remaining payload capacity when we issue the
invoice. The latter is required to pass the information on to you. If this
has not been done, you can contact your dealer and ask for the informa-
tion. Our scales meet all legal and standard requirements and are regu-
larly maintained, tested and calibrated. A slight tolerance is nevertheless
technically unavoidable. In addition, the weight of the vehicle may vary
slightly due to weather conditions and, for example, the associated ab-
sorption or release of moisture. The real weight of the vehicle can there-
fore deviate by a few kilograms from the reported real weight.
The payload is made up as follows:
⚫ Conventional load
⚫ Special equipment
⚫ Personal equipment
The vehicle's payload can be increased by reducing the actual weight.
To do this, it is allowed for example to empty the fluid containers or to re-
move the gas bottles.
Remaining payload
capacity
