Electrical system 8
B-MC I/T - 01/23-1 - EHG-0016-03EN 141
8.6.4 Charging the battery
When the vehicle engine is running, a relay in the transformer/rectifier alter-
nator switches on the living area battery and the starter battery together and
recharges them with the vehicle generator. When the vehicle engine is swit-
ched off, the batteries are automatically disconnected from one another
again by the transformer/rectifier. This prevents the starter battery from
being run down by electrical appliances in the living area. The starting capa-
bility of the vehicle is thus preserved. The terminal voltage of the living area
battery or the starter battery can be read on the panel.
If the vehicle is connected to the 230 V power supply via the CEE socket
outlet, the living area battery and the starter battery are charged by the char-
ger module on the transformer/rectifier. The starter battery is only charged
with a float charge. The charging current is adapted to suit the charging con-
dition of the battery. This ensures that it is not possible to overload the bat-
tery.
To make use of the maximum output from the charger module on the trans-
former/rectifier, switch off all electrical appliances during charging.
8.6.5 Retrofitting additional 12 V appliances
The electrical system in the living area of the vehicle may be equipped with
optional devices. The optional devices are to be connected to the reserve
outputs on the transformer/rectifier. The output of the optional devices may
not exceed the rating of the fuse (e.g. 15 A). Do not use fuses on the trans-
former/rectifier that are higher than those stated on the transformer/rectifier.
8.7 Transformer/rectifier (EBL 402)
The unit contains parts that carry 230 V mains voltage. Potentially fa-
tal electric shock or fire hazard!
Do not carry out any maintenance or repair work on the unit. If the
cable or housing is damaged, do not put the unit into operation and
disconnect it from the mains supply. Do not allow liquid to enter the
unit.
Replace defective fuses only when the unit is de-energised.
Only replace defective fuses when the cause of the defect is known
and has been remedied.
Never bypass or repair fuses.
Only use original fuses with the values specified on the unit.
Device components can get hot during operation. Do not touch.
Do not cover the ventilation slots. Danger of overheating!
Do not store any heat-sensitive objects close to the unit (e.g. tempera-
ture-sensitive clothes if the unit is installed in the wardrobe).
Observe the safety instructions and information in the separate device
manufacturer's instruction manual.
