28
2.7 Check your electrical installation
This equipment is intended to be connected to an outlet with 115V/ 60Hz/ 1
phase.
2.8 Electrical, drain and refrigeration connections (remotes only)
Installation and service must be performed by a qualified technician.
All electrical connections must be
done from the electrical board
Equipments for remote installation
come with nitrogen under
pressure and an easy prep kit
(tubing connections needed only)
for installation.
Prepare a drain installation
Nema-5-15P Nema-5-20P
Label 15
Warning
- This appliance requires a properly grounded dedi-
cated circuit using a NEMA rated wall receptacle do
not remove the grounding prong on the plug or the
risk of an injury due to shock from the ungrounded
electrical service may occur.
- This product can expose an individual to chemi-
cals that have been identifi ed by the state of Cali-
fornia to possibly be dangerous leading to various
diseases birth defects or other human reproductive
system harm. For more information go to
www.p65warnings.ca.gov.
41
All self contained KPM series use the following equipment: capillary tube, finned coil
ventilated systems (condenser/evaporator), hermetic compressor, electrical water
evaporation system.
Model
Circuit
pressure
(psig)
Refrigerant
and charge
(OZ)
Defrost
R 404A 19,40
R 404A 25,39
R 404A 37,74
Automatic 3/day
Automatic 3/day
Automatic 3/day
High side Low side
174
174
174
331
331
331
KPM-CG/FG/OF-60-S
KPM-CG/FG/OF-80-S
KPM-CG/FG/OF-100-S
|
|
|
|
|
|
|
|
|
3.2 Refrigeration loads (remotes only)
Installation of remote equipment must be done by a qualified technician.
Model
BTU*/h
2959
3253
4372
TS2
TS2
TS2
00
00
00
Expansion
valve type
*values presented are indicative for 14°F evap, and 90°F ambient.
KPM-CG/SC/FG/SF/OF/SO-60-R
KPM-CG/SC/FG/SF/OF/SO-80-R
KPM-CG/SC/FG/SF/OF/SO-100-R
|
|
|
|
|
|
4 Electrical
4.1. Electrical specifications data
Electrical data can be found on the marking plate.
Standard equipment include led lighting and anti condensation system.
