Self contained control panel
(KFM-CG/FG/OF/SC/SF/SO)
Hot key connector
Electronic controller
Light switch
Power signal
Condensing unit switch
Electrical board
2.4 Control panel and main features
The pictures below, shows the main features and all necessary controls.
Remote control panel
(KFM-CG/FG/OF/SC/SF/SO)
Electrical board
Electronic controller
Light switch
Power signal
Condensing unit switch
51
All self contained KFM series use the following equipment: capillary tube, finned coil
ventilated systems (condenser/evaporator), hermetic compressor, electrical water
evaporation system.
Model
Circuit
pressure
(psig)
Refrigerant
and charge
(OZ)
Defrost
R 404A 14,10
R 404A 19,40
R 404A 19,40
R 404A 25,39
R 404A 37,74
R 404A 42,33
Automatic 3/day
Automatic 3/day
Automatic 3/day
Automatic 3/day
Automatic 3/day
Automatic 3/day
High side Low side
174
174
174
174
174
174
331
331
331
331
331
331
KFM-CG/SC/FG/SF/
OF/SO-40-S
KFM-CG/SC/FG/SF/
OF/SO-50-S
KFM-CG/SC/FG/SF/
OF/SO-60-S
KFM-CG/SC/FG/SF/
OF/SO-80-S
KFM-CG/SC/FG/SF/
OF/SO-100-S
KFM-CG/SC/SF/FG/
OF/SO-120-S
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
3.2 Refrigeration loads (remotes only)
Installation of remote equipment must be done by a qualified technician.
Model
BTU*/h
2548
3015
3159
4345
5112
5472
TS2
TS2
TS2
TS2
TS2
TS2
00
00
00
00
00
00
Expansion
valve type
*values presented are indicative for 14°F evap, and 90°F ambient.
KFM-CG/SC/FG/SF/OF/SO-40-R
KFM-CG/SC/FG/SF/OF/SO-50-R
KFM-CG/SC/FG/SF/OF/SO-60-R
KFM-CG/SC/FG/SF/OF/SO-80-R
KFM-CG/SC/FG/SF/OF/SO-100-R
KFM-CG/SC/FG/SF/OF/SO-120-R
|
|
|
|
|
|
|
|
|
|
|
|
