20
Self contained control panel
Electronic controller
Light switch
Power signal
Power switch
Electrical board
Hot key connector
Evap pan outlet
Remote control panel
Electronic controller
Light switch
Power signal
Power switch
Possible damage on the unit must be checked to file a claim near the transportation
company.
The unit must be checked in the following points:
Exterior panels
Doors
Shelves
Glasses
Paint job
Door handles
Base structure
2.4 Control panel and main features
The pictures under, shows the main features and all necessary controls.
57
5.8 Evap Pan cleaning
This operation must be performed by a qualified technician.
All operations must be done with the unit disconnected.
Pan can be hot!
This operation must be done weekly.
To access the evap pan:
- Remove prtection grille.
- Unplug the evap pan.
- Relieve the screws and take the evap pan off.
- Clean with soft detergent or warm water.
