EMBROIDERY SET UP

CONNECT THE EMBROIDERY UNIT

 6OLGHWKHDFFHVVRU\ER[RII

 7KHUHLVDVRFNHWDWWKHEDFNRI WKHPDFKLQH$6OLGHWKH

embroidery unit onto the free arm of the machine until

LWSOXJVÀUPO\LQWRWKHVRFNHW,IQHHGHGXVHWKHOHYHO

adjusting feet so that the machine and embroidery unit are

even. If the machine is turned off, turn it on.

3. A pop-up message tells you to clear the embroidery

area and remove the hoop for calibration. Press OK.

The machine will calibrate and the embroidery arm will

move to the ready position. This calibration will set

your embroidery functions each time you slide on the

embroidery unit.

Note: DO NOT calibrate the machine with the embroidery hoop

attached as this can damage the needle, presser foot, hoop and/or the

embroidery unit. Be sure to clear all materials from around the machine

before calibrating so the embroidery arm does not bump into anything

while calibrating.

REMOVE THE EMBROIDERY UNIT

1. To store the embroidery unit, remove the hoop and

move the embroidery arm to Park Position by pressing

the Needle Up/Down button. You can also select Park

Position in the Hoop Options Menu. Press the Hoop

Options button to enter the menu.

Note: It is very important that the hoop is removed, otherwise the

hoop, needle or presser foot may be damaged.

2. Press the button at the left, underneath the embroidery

XQLW%DQGVOLGHWKHXQLWWRWKHOHIWWRUHPRYHLW

ATTACH THE EMBROIDERY FOOT R

:KHQHPEURLGHULQJXVHWKH(PEURLGHU\IRRW56HHSDJH

for instructions on how to change presser foot.

Note: You can also use the optional Sensor Q-foot when embroidering

(part number 413192045). The machine needs to be set in Free Motion

Spring Action Mode when embroidering with the optional Sensor Q-foot,

see page 31.
