WINDING THE BOBBIN WITH

THE MACHINE THREADED

Make sure that the presser foot is up and the needle is in the

highest position.

Note! Do not use a plastic presser foot when bobbin winding.

1. Place an empty bobbin on the bobbin spindle on the top

of the machine. The EREELQRQO\ÀWVRQRQHZD\ZLWK

WKHORJRIDFLQJXS8VHRQO\RULJLQDO+8649$51$

9,.,1*

bobbins.

2. Pull the thread from the needle under the presser foot and

WRWKHULJKWWKURXJKWKHWKUHDGJXLGH&

 *XLGHWKHWKUHDGWKURXJKWKHKROHLQWKHEREELQ'IURP

the inside to the outside.

Note: When using an earlier version of HUSQVARNA VIKING

bobbins that do not have a hole, wind several turns of thread on the

bobbin to get started.

4. Push the bobbin spindle to the right. A pop-up message

appears on the GraphicDisplay. Hold the end of the

WKUHDGÀUPO\ZKHQVWDUWLQJWRZLQG3UHVVWKHIRRWFRQWURO

to start winding. Once the bobbin begins to wind, cut the

excess thread. When the bobbin is full it will stop rotating.

Release the foot control. Push the bobbin spindle back to

the left, remove the bobbin and cut off the thread on the

thread cutter.

WINDING THE BOBBIN USING

THE VERTICAL SPOOL PIN

1. Place an empty bobbin on the bobbin spindle on the top

RI WKHPDFKLQH7KHEREELQRQO\ÀWVRQRQHZD\ZLWK

WKHORJRIDFLQJXS8VHRQO\RULJLQDO+8649$51$

9,.,1*

bobbins.

2. Place the large spool cap and a felt pad under the spool on

the main spool pin set in the vertical position.

3. Bring the thread over and behind the pre-tension thread

JXLGH$DQGGRZQDURXQGWKHWKUHDGWHQVLRQGLVF%

WKHQWKURXJKWKUHDGJXLGH&DVLOOXVWUDWHG

 *XLGHWKHWKUHDGWKURXJKWKHKROHLQWKHEREELQ'IURP

the inside to the outside.

5. Push the bobbin spindle to the right. A pop-up message
