8
1886
1886
Installing the Glass
NOTE: Check to ensure
proper engagement.
Attach the globe by lifting and
turning clockwise one third of a
full turn of the glass until it stops.
WARNING
GLASS FALL HAZARD
To prevent SERIOUS INJURY or DEATH, make
sure that glass is properly secured.
Lift the globe and align the
notches in the globe with
the tabs in the light kit.
Notch
Tab
Assembling the Light Kit
Insert the third screw,
found in the hardware
bag, into place and then
tighten all three screws.
Partially install two light kit
assembly screws, found in the
hardware bag, halfway into
the motor housing as shown.
It does not matter which two
screw holes you choose.
Feed the wire plugs
through the center hole of
the upper switch housing,
then wrap keyhole slots
around the screws and twist
counterclockwise.
WARNING
FAN FALL HAZARD
Make sure all screws are tight to secure
the light xture.
2 of 6
Light Kit Screw
bag
1 of 6
Light Kit Screw
bag
3 of 6
Light Kit Screw
bag
Ceiling Bracket Hanging Fan Wiring Installing Fan Body Blades Light Remote App
Lift the LED assembly and connect the
single-pin connectors to the connectors from
the fan. Connect the white wires together.
Connect the blue and black wires together.
Align the holes of LED assembly with
the holes of the upper switch housing.
Make sure all the wires from the fan
and the light kit are snug inside the
center of the light kit, not pinched in
between the upper switch housing and
the light kit or hanging out of the sides.
Insert the light kit screws, found in the
hardware bag. Tighten all three screws.
ON
Turn Power
