12
Installation - Stem Mount
A. Stem Mount with 1"-14 Thread
Use the following instructions to stem mount the Sensor:
CAUTION
Do NOT mount the Sensor to a stem mount or antenna pole that contains ferrous
metals.
NOTE
It is important to review the mounting considerations and test run the cable route
as indicated in Section 1 before proceeding with the installation.
1. If you have a pre-existing stem mount, skip to step 2.
If you need to mount the antenna pole (stem), mark the chosen
mounting location and drill a 5/8" (15.9 mm) hole for the cable and
cable connector.
If you have purchased hardware to stem mount your Sensor, follow
the instructions included with that hardware to attach the stem to
the boat.
2. Screw the sensor base onto the stem first, making sure that the stem
pipe does not protrude from the sensor base. (This adds protection to the
cable when it is pulled through the pipe stem.) Deburr the pipe edges to
reduce cable abrasion.
3. Route the Sensor cable through the stem and through the planned
cable route.
4. Position the sensor so the arrow on the cover is pointed straight toward
the front of the boat in the direction of travel. The arrow should be
parallel with the keel.
NOTE
Failure to align the sensor correctly will result in incorrect compass readings.
