Switchblade

9 Technical Specifications

All level indications relate to 0 dBV (1V RMS).

9.1 Inputs

INSTRUMENT Input

Input: 6.3 mm (1/4") jack

Type: unbalanced

Input impedance: 1 M ohms

Sensitivity: - 50 dB (Clean Channel)

Max. Input Level: 0 dB

FX Return

Input: 6.3 mm (1/4”) jack

Type: unbalanced

Input impedance: 48 k ohms

Max. sensitivity: -10 dB button engaged: - 21 dB,

disengaged: - 11 dB

Max. Input Level: -10dB button engaged: + 0 dB,

disengaged + 10 dB

MIDI IN

Port: DIN 45 329 (7-pin )

Data reception: Program change data, Tap Delay function

Channels: 16, Omni mode

Power supply: 15V DC max. 200mA, pin 6 = positive,

pin 7 = negative

9.2 Outputs

FX Send

Output: 6.3 mm (1/4") jack

Type: unbalanced

Output impedance: 2.2 k ohms

Output Level: + 3 dB

Max. output Level: -10dB button engaged: - 2 dB,

disengaged: + 8 dB

MIDI THRU

Port: DIN 45 328 ( 5-pin)

Data handling: All data sent to MIDI IN are patched

out unchanged.

Speaker Outputs

6.3 mm (1/4") jacks: 1 x 4 ohms, 2 x 16 ohms / 1 x 8 ohms,

1 x 16 ohms

Speaker

100 Combo 2 x 12" Eminence® Rockdriver 60

50 Combo 1 x 12" Eminence® Rockdriver 60

9.3 General Electrical Data

Switchblade 100 Head/Combo Switchblade 50 Combo

Max. current consumption:

440 watts 290 watts

Max. power consumption:

1.75A @ 240 volts 0.97A @ 240 volts

1.89A @ 220-230 volts 1.07A @ 220-230 volts

3.50A @ 117-120 volts 2.00A @ 117-120 volts

3.95A @ 100 volts 2.15A @ 100 volts

Mains voltage tolerance range: +/- 10 %

External fuses (anode):

1 x T 630 mA 1 x T 400 mA

Internal fuses:

1 x TT 10 A super slow blow 1 x TT 10 A super slow blow

2 x T 630 mA 2 x T 630 mA

Mains fuse (5 x 20 mm):

Europe: (variable: 220 V-230 V / 240 V)

1 x 250 V / T 1.6 A 1 x 250 V / T 1 A

USA/Canada/Asia: (variable: 100 V / 120 V)

1 x 250 V / T 4 A 1 x 250 V / T 2 A

Ambient operating temperature range:

0 °C to + 35 °C 0 °C to + 35 °C

9.4 General Mechanical Data

100 Head 100 Combo 50 Combo

Dimensions: (including corners, handles, feet)

Width: 750 mm 647 mm 600 mm

Height: 280 mm 500 mm 500 mm

Depth: 258 mm 285 mm 285 mm

Weight: 17.6 kg 30.3 kg 22.8 kg
