Statesman Series

english

5. Technical Data

All level indications relate to 0 dBV (1V RMS)

Inputs

INSTRUMENT input

Jack: spring jack

Input design: balanced

Input impedance: 1M ohm

Sensitivity: -22 dBV / 1 kHz (with Clean, all controllers in middle position)

Maximum input level: 1.3 dBV / 1 kHz

FX Return

Jack: spring jack

Input design: balanced

Input impedance: 48k ohm

Maximum sensitivity: -10 dBV

Outputs

FX Send

Jack: spring jack

Output design: balanced

Output impedance: 2k ohm

Output level: -10 dBV / 1 kHz (with Clean, all controllers in middle position)

Maximum output level: -3 dBV / 1 kHz

Speaker connection

Spring jack: 1 x 8-16 ohm, parallel to internal speaker

Speaker

1x 12" Eminence Rockdriver Cream, 60 watts, 8 ohm

General electrical data

DUAL EL84 QUAD EL84

Maximum power consumption:

130 watts 200 watts

Maximum turn-on power consumption (in-rush current)

8A @ 240 volts 12A @ 240 volts

8A @ 220-230 volts 12A @ 220-230 volts

16A @ 117-120 volts 19A @ 117-120 volts

17A @ 100 volts 20A @ 100 volts

Range of supply voltage:

+/- 10 %

External fuses (anode voltage):

1 x T 250 mA 1 x T 400 mA

Internal fuses:

16 VAC 1 x T 630 mA 16 VAC 1 x T 630 mA

6.3 VAC 1 x T 4A 6.3 VAC 1 x T 5A

Mains fuse (5 x 20 mm):

Europe: (switchable: 220-230 V / 240 V)

1 x 250 V / T 500 mA 1 x 250 V / T 800 mA

USA / Canada / Asia: (switchable: 100 V / 120 V)

1 x 250 V / T 1 A 1 x 250 V / T 1,6A

Ambient temperature range in operation:

0 °C to + 35 °C 0 °C to + 35 °C

General mechanical data:

Dimensions: (with corners, handles and feet)

560 x 470 x 250 mm 620 x 490 x 250 mm

Weight:

19.5 kg 21.9 kg
