RED CHANNEL SELECT LED: This one

illuminates up to indicate the LEAD channel is

active.

GAIN: Rotate this knob to determine the amount of

distortion in the LEAD channel.

MASTER: Dial this knob to control the LEAD

channel’s volume level.

EQ SECTION: The Bass, Mid and Treble knobs

affect both channels. Mid and Treble influence

one another, an attribute considered normal and

desirable in a tube amp. Boosting treble decreases

midrange honk and vice versa: jacking up the mids

cuts back on the high-end shimmer.

REVERB: Controls the intensity of the on-board

reverb effect.

POWER: The Edition Tube’s mains power switch.

MAINS IN: Connect the included Euro-norm mains

cord to this socket. Ensure the amp's voltage rating

matches your local AC power rating before you plug

the cord into the wall outlet.

EXTERNAL SPEAKER: Use this jack to connect

external speaker enclosures with an overall

impedance ranging from 8 to 16 ohms (an 8-ohm

cabinet, for example, would work nicely). The

internal loudspeaker remains in operation.

RETURN: Connect this jack to the output of your

signal processor.

SEND: Connect this jack to the input of your signal

processor.

2.0 Standard Setup/

Cable Connections

3.0 Operation

3.1 Selecting Sounds

When you’re ready to tweak the settings for both of

the fundamental sounds that the Edition Tube has to

offer, we recommend you proceed as follows:

• Dial in all your sound settings with the guitar’s

volume knob turned all the way up so that it give

the amp the highest possible level to work with.

• First concentrate on tuning the CLEAN channel

VOLUME knob to dial in the desired volume level

and amount of overdrive.

• Once you’re satisfied with that sound, activate the

LEAD channel and use the GAIN knob to shape

the second fundamental sound to suit your taste.

• Now adjust the LEAD MASTER to dial in the

desired balance of levels between the LEAD and

CLEAN channels.

3.2 Using Signal Processors

The Edition Tube is equipped with a serial effects

loop. This means that the entire preamp signal is

routed to the FX device and processed there. For

this reason, use only high-quality signal processors

that do not color the signal unnecessarily, add undue

noise, or impair its sound quality.

Connecting effect devices:

• Connect the SEND jack to the processor‘s input,

and the RETURN jack to the processor‘s output.

• To avoid noise, signal loss, and signals from being

cut off, use high-quality patch cords only.

• Make sure the processor is not distorting the

signal. Check the processor's level meter and use its

input and output controls to dial in a suitable level.

• Unless you’re going for bizarre lo-fi effects,

distortion devices are not designed for use in an FX

loop. As a rule of thumb, any kind of device that

compresses the signal should be connected first in

the signal chain. Depending on the type of effect

you want to achieve, you may want to connect a

compressor to the amp's input.

• If you are using several processors or stomp boxes,

ensure you connect them in the proper sequence.

Volume pedals, wah-wahs and the like evoke a

slightly different sound and elicit a different response

when you plug them into the Edition Tube’s front

panel input rather than the effects loop. Both can

sound hip, so which option you choose is a matter of

personal preference.
