Rows of series installation
L ≤ H
L ≤ 1/2H
L A
25 cm / 9.8” or more
1/2H < L ≤ H
30 cm / 11.8” or more
L > H
Can not be installed
The relations between H, A and L are as follows
W
H
A
B
D
Outdoor Unit Dimentsion (mm) Mounting Dimentsion (mm)
W H
D
A
B
681 434 285 460 292
700 550 275 450 260
300
333
363
420
555
554
702
810
770
800
845
946
487
514
540
673
298
340
350
403
4171333958 634 404
L
H
300 cm / 118” or more
A
60 cm / 23.6”
or more
150 cm / 59”
or more
25 cm / 9.8”
or more
25 cm / 9.8”
or more
Refrigerant Piping Connection
When connecting refrigerant piping, do not
let substances or gases other than the specified
refrigerant enter the unit. The presence of other gases or substances will lower the unit’s capacity,
and can cause abnormally high pressure in the refrigeration cycle. This can cause explosion and injury.
Please check the elevation difference between the indoor unit and the outdoor unit, the length
of the refrigerant pipe, and the curved places (bend) of the pipe as following:
Elevation difference: no more than 10 M
Pipe length: no more than 20 M
Bends: no more than 5 places
A minimum pipe run of 3 metres is required to
minimise vibration & excessive noise.
Note on Pipe Length
27
