2
Introduction
The Z4 G5 has been redesigned to deliver support for the latest processor, memory, graphics, and storage technologies.
There are three 90% efficiency-rated power supplies that qualify for 80 PLUS GOLD status*.
The Z6 G5 has been redesigned to deliver support for the latest processor, memory, graphics, and storage technologies.
There are two 90% efficiency-rated power supplies that qualify for 80 PLUS GOLD status*.
In order for the system to turn on with these new power supplies, the system side panels must be fully seated. The system
will error and provide a Three Red/4 White beep code.
* The 80 PLUS specification states that all GOLD power supplies achieve at least 87%/90%/87% efficiency at 115V and
90%/92%/89% efficiency at 230V for 20%/50%/100% of rated output, respectively.
Power consumption and cooling considerations
An HP workstation might require more power than the typical office environment can supply.
An 1125W fully loaded configuration might draw up to the system’s maximum rating of 12A at 110V power, leaving no
power for other accessories.
• An office air conditioning system must accommodate the extra heat generated by fully loaded workstation
configurations.
• Some environments might have power quality problems that prevent the reliable use of high-end workstation
configurations. Possible problems include power failure, voltage sag, voltage surge, voltage spike, brownout, line
noise, frequency variation, and switching transient and harmonic distortion.
• If your workstation is powered from a >200V source and you meet the HP configuration guidelines, you will not need an
uninterruptible power supply (UPS) to achieve maximum power output.
Power consumption limitations
– The Z4/Z6 G5 1125W power supplies are capable of multiple output power wattages depending on the input voltage.
It is not recommended to operate in an environment that drops below 90V for any reason (for example, brownout or
line sag) as the AC brown out voltage detection circuit for the power supply may be triggered and shut the PSU down
unexpectedly. A UPS is highly recommended to achieve maximum output power when used at 100V.
Input Voltage and Maximum Output Power Summary
Z4 G5 maximum power output
Input voltage
<90V
>90V
>104V
>180V
1125W PSU
Not recommended
1125W
1275W
1450W
775W PSU
Not recommended
775W
775W
775W
525W PSU
Not recommended
525W
525W
525W
Z6 G5 maximum power output
Input voltage
<90V
>90V
>104V
>180V
1125W PSU
Not recommended
1125W
1275W
1450W
775W PSU
Not recommended
775W
775W
775W
Uninterruptible power supply (UPS)
• What is a power interruption?
A power interruption can take the form of a power failure (blackout), voltage sag, voltage surge, voltage spike, brownout
(drop), line noise, frequency variation, and switching transient and harmonic distortion.
• What is an uninterruptible power supply (UPS)?
