6 Removal and replacement procedures –
tablet
The HP ElitePad 1000 G2 is also spared as a whole unit using an advanced exchange strategy using the spare
part number 764967-ABB.
CAUTION: Components described in this chapter should only be accessed by an authorized service provider.
Accessing these parts can damage the tablet and void the warranty.
NOTE: HP continually improves and changes product parts. For complete and current information on
supported parts for your computer, go to http://partsurfer.hp.com, select your country or region, and then
follow the on-screen instructions.
This chapter provides removal and replacement procedures for authorized service provider only parts.
There are as many as 34 screws that must be removed, replaced, and/or loosened when servicing the tablet.
Make special note of each screw size and location during removal and replacement.
Display assembly
Description Spare part number
10.1-in., WUXGA (1900×1200), UWVA, 50% CG, 400-nit, active pen and MultiTouch capacitive digitizer,
chemically-strengthened glass with anti-smudge; includes display panel, display LVDS cable,
TouchScreen cable, and display panel support rubber
747658-001
Before disassembling the tablet, follow these steps:
1. Turn o the tablet. If you are unsure whether the tablet is o or in Hibernation, turn the tablet on, and
then shut it down through the operating system.
2. Disconnect the power from the tablet by unplugging the power cord from the tablet.
3. Disconnect all external devices from the tablet.
Remove the display assembly:
1. Remove the two Phillips PM1.4×3.2 screws that secure the display assembly to the tablet.
Display assembly 27
