Table 1-3 Printer rear view (continued)
Feature Description
2 Power connection
3 USB port
4 Ethernet port (Ethernet model only)
Printer inner view
Table 1-4 Printer inner view
Feature Description
1 Tank covers
Tank covers enclose the ink tanks on both sides of the printer.
2 Tank caps
Tank caps are plugs to seal the opening of the ink tanks.
3 Ink tanks
There are four ink tanks. Each tank contains a dierent colored ink: black, yellow, magenta, and
cyan.
4 Printhead cover
The printhead cover on the print carriage secures the printheads in the carriage. Make sure the
printhead cover is properly closed to avoid problems such as carriage jams.
CAUTION: After you have set up the printer, do not open the printhead cover unless instructed to do
so.
5 Printhead cover button
Press to open the printhead cover.
CAUTION: After you have set up the printer, do not open the printhead cover unless instructed to do
so.
6 Ink tubes button
Printer inner view 3
