Display panel
Description Spare part number
Display bezel 697907-001
35.6 cm (14.0 in), HD, WLED, SVA BrightView flat display panel 698523-001
IMPORTANT: Make special note of each screw and screw lock size and location during removal
and replacement.
Before removing the display panel, follow these steps:
1. Shut down the computer.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet
and then unplugging the AC adapter from the computer.
4. Remove the battery (see
Battery on page 35).
NOTE: To replace the entire display assembly, additional steps are required (see Display assembly
on page 71).
Remove the panel:
1. Remove the plastic screw covers (1) and the two Phillips screws (2) that secure the display
bezel to the display assembly.
2. Flex the inside edges of the bottom edge (1), the left and right sides (2), and the top edge (3) of
the display bezel until the bezel disengages from the display enclosure.
Component replacement procedures 37
