3. (UMA models only) Remove the fan duct (see Fan duct (UMA models only) on page 22).
Remove the solid-state drive:
1. Remove the Phillips M2.0 × 3.0 screw (1) that secures the drive.
2. Pull the drive (2) out of the socket.
To install the solid-state drive, reverse the removal procedure.
WLAN module
To remove the WLAN module, use these procedures.
Table 4-5
WLAN module descriptions and part numbers
Description Spare part number
Realtek RTL8852CE + Bluetooth 5.3 N19618-001
Realtek RTL8852BE-VT + Bluetooth 5.4 P06350-001
WLAN module antenna cover N44228-001
Before removing the WLAN module, follow these steps:
1. Prepare the computer for disassembly (see Preparation for disassembly on page 19).
2. Remove the access panel (see Access panel on page 19).
Remove the WLAN module:
1. Remove the Phillips screw (1) from the module, and then remove the antenna protector (2).
2. Disconnect the antenna cables (3) from the module.
24
Chapter 4 Removal and replacement procedures
