Pull the three tabs (1) upward, and then rotate the bezel (2) off the computer.
To install the front bezel, reverse the removal procedure.
Fan duct
The fan duct sits on the heat sink and is secured to it with tabs. To remove the fan duct, use these
procedures.
Table 4-3
Fan duct description and part number
Description Spare part number
Fan duct (includes thermal pad) P26757-001
Before removing the fan duct, follow these steps:
1. Prepare the computer for disassembly (see Preparation for disassembly on page 19).
2. Remove the access panel (see Access panel on page 19).
Remove the fan duct:
1. Slide the back of the duct (1) into the computer.
22
Chapter 4 Removal and replacement procedures
