Illustrated parts catalog
Maintenance and Service Guide 3–3
Item Description Spare Part Number
(1) Display assembly, 15.6-inch WXGA BrightView (includes webcam, 2 microphones, and 2 wireless antenna
transceivers and cables)
For use in white computers 578257-001
For use in black computers 578256-001
(2) Switch cover (includes LED board and cable)
For use in white computers 571747-001
For use in black computers 571757-001
(3) Power button board (includes cable) 512834-001
(4) Keyboard (includes keyboard cable)
✎
For a detailed list of available keyboards, see “Sequential part number listing” on page 3-12.
White painted keyboard 517864-xxx
White molded keyboard 517863-xxx
Black painted keyboard 518965-xxx
Black molded keyboard 518966-xxx
Black textured keyboard 570228-xxx
(5) Bluetooth module
✎
The Bluetooth module cable is available using spare part number 579161-001.
537921-001
(6) Top cover (includes TouchPad and TouchPad buttons)
For use only with white computer models equipped with a fingerprint reader 579159-001
For use only with white computer models not equipped with a fingerprint reader 518108-001
For use only with black computer models equipped with a fingerprint reader 579160-001
For use only with black computer models not equipped with a fingerprint reader 518788-001
(7) Speaker assembly 533865-001
(8a)
(8b)
(8c)
Plastics Kit, includes:
ExpressCard slot bezel
Memory module compartment cover
Hard drive cover
✎
See “Plastics Kit” on page 3-9 for more information.
511890-001
(9) ExpressCard module 464793-002
(10) USB board (includes cable) 516497-001
(11) System board (includes replacement thermal material)
For use in computers equipped with UMA graphics subsystem memory 571186-001
For use in computers equipped with discrete graphics with 1 GB of dedicated memory 571187-001
For use in computers equipped with discrete graphics with 512 MB of dedicated memory 571188-001
(12) Modem module
✎
The modem module spare part kit does not include a modem module cable. The
modem module cable is included in the Cable Kit, spare part number 533466-001. For
more information, see “Cable Kit” on page 3-10.
For use in all countries and regions except Australia and New Zealand 510100-001
For use only in Australia and New Zealand 510100-011
(Continued)
